Centralized Management: for up to 1,000 Omada access points, 100 Omada routers, a maximum of 200 Omada switches, and a maximum of 10 certain DeltaStream GPON OLTs†
The Omada hardware controller (OC400) for the Omada Software Defined Networking (SDN) platform, supports centralized
management for up to 1,000 Omada access points, 100 Omada routers, a maximum of 200 Omada switches,
and a maximum of 10 certain DeltaStream GPON OLTs†. Enjoy cloud service with no license fees with the use of OC400.
• 2× 10G SFP+ Ports
• 4× GE RJ45 Ports
• 2× USB 3.0 Ports
• 1× GE Console Port
Fan Quantity
1
Button
• 1× Reset
Power Supply
100-240 V ~ 50/60 Hz AC
Dimensions ( W x D x H )
17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
Management Features
Omada App
Yes
Centralized Management
• 1,000 Omada access points
• 100 Omada routers
• A maximum of 200 Omada switches†
• A maximum of 10 certain DeltaStream GPON OLTs†Note: Please refer to www.tp-link.com/en/business-networking/all-omada/ to find all the Omada device models supported by OC400 †The number of supported Omada switches decreases by 5 for each DeltaStream GPON OLT added. The DeltaStream GPON OLTs supported by the controller are DS-P7001-04 and DS-P7001-08.
