TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera
TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera - Image 2
TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera - Image 3
TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera - Image 4
TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera - Image 5
,

TP-Link InSight S385 VIGI 8MP 4mm Outdoor Full-Color Bullet Network Camera

TP-Link
Add to wishlist
Compare

Human & Vehicle Classification Distinguish humans and vehicles from other objects and receive more accurate event notifications.

Check Delivery Availability

₹16,999.00 ₹19,999.00 Inc. GST

Available Offers
  • save300 โ€“ Use this code & get 300 off
cash on delivery icon
Compare
  • 4K (8MP) Ultra HDย andย 24h Full-Color
  • People & Vehicle Analyticsยง
  • Human & Vehicle Classification
  • Smart Detection
  • Smart Video Enhancement Technology
  • Active Defense and Two-Way Audio
  • IP67 Waterproof
  • H.265+ Compression Technology
  • 12V DC/PoE
SKU: InSight S385 Categories: ,
Brands

TP-Link
CAMERA
Image Sensor 1/2.7โ€ Progressive Scan CMOS
Shutter Speed 1/3 to 1/10000 s
Slow Shutter Yes
Minimum Illumination 0.005 Lux; 0 Lux with IR/White light
Day/Night Mechanism IR Cut Filter
Day/Night Switch Unified/ Scheduled/ Auto
LENS
Type Fixed Focal Lens
Focal Length 2.8/4 mm
Aperture F1.6
FOV โ€ข 2.8 mm:
Horizontal FOV: 111.4ยฐ, Vertical FOV: 58.8ยฐ, Diagonal FOV: 134ยฐ

โ€ข 4 mm:
Horizontal FOV: 91.5ยฐ, Vertical FOV: 46.1ยฐ, Diagonal FOV: 109.6ยฐ
Lens Mount M12*P 0.5
DORI Distance โ€ข 2.8 mm
Detect: 85 m (278 ft)
Observe: 35 m (116 ft)
Recognize: 17 m (56 ft)
Identify: 8 m (28 ft)

โ€ข 4 mm
Detect: 107 m (350 ft)
Observe: 44 m (146 ft)
Recognize: 21 m (70 ft)
Identify: 11 m (35 ft)
Angle Adjustment (Manual)
Range Pan: 0ยฐ to 360ยฐ, Tilt: 0ยฐ to 90ยฐ, Rotation: 0ยฐ to 360ยฐ
ILLUMINATOR
IR LED โ€ข Quantity: 2
โ€ข Range: 30m
โ€ข Wavelength: 850nm
White LED โ€ข Quantity: 2
โ€ข Range: 30m
Illuminator On/Off Control Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution 3840 X 2160
Main Stream โ€ข Frame Rate๏ผš
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

โ€ข Resolution:
3840×2160, 2560×1440, 2304×1296, 2048×1280, 1920×1080,
1280×720

โ€ข Note:
If the image rotation is set to 90ยฐ or 270ยฐ, the frame rate only supports up to 20fps.
If 120dB is turned on, the frame rate can only support up to 20fps.
Sub-Stream โ€ข Frame Rate๏ผš
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps

โ€ข Resolution:
848×480, 704×576, 640×480, 640×360, 352×288, 320×240

โ€ข Note:
If the image rotation is set to 90ยฐ or 270ยฐ, the frame rate only supports up to 20fps.
If 120dB is turned on, the frame rate can only support up to 20fps.
Bit Rate Control CBR, VBR
Video Compression โ€ข Main Stream: H.265+/H.265/H.264+/H.264
โ€ข Sub-Stream: H.265/H.264
H.264 Type High Profile
H.264+ Main Stream Supported
H.265 Type Main Profile*
H.265+ Main Stream Supported*
Video Bit Rate โ€ข Main Stream: 256 Kbps to 8 Mbps
โ€ข Sub-Stream: 64 Kbps to 512 Kbps
Image Settings โ€ข Mirror
โ€ข Brightness
โ€ข Contrast
โ€ข Saturation
โ€ข Sharpness
โ€ข Exposure
โ€ข WDR
โ€ข White Balance
โ€ข Prevent Overexposure to Infrared Light
โ€ข HLC Adjustable by Client Software
Image Enhancement BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range 120 dB

Note: When People & Vehicle Analytics is enabled, only DWDR is supported.
SNR โ‰ฅ 52 dB
Image Parameters Switch Yes
Privacy Mask Up to 4 Masks
ROI 1 Region
OSD Setting Yes
AUDIO
Audio Communication Two-Way Audio
Audio Input Yes
Audio Output Yes
Audio Compression Yes
Audio Sampling Rate 8KHz
Environment Noise Filtering Yes
Audio Bit Rate 64 Kbps(G.711 alaw)
NETWORK
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
ONVIF Yes
API ONVIF (Profile S/T/G)
Simultaneous Live View 3 Main Streams & 3 Sub-Streams
Client VIGI App, VIGI Security Manager, Web UI, VIGI VMS, VIGI Cloud VMS
Web Browser โ€ข Google Chromeยฎ 57 and above
โ€ข Firefoxยฎ 52 and above
โ€ข Safariยฎ 11 and above
โ€ข Microsoftยฎ Edge 91 and above
Cloud Yes
Security Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
ALARM AND EVENT MANAGEMENT
Smart Event โ€ข Intrusion Detection
โ€ข Line-Crossing Detection
โ€ข Region Entering Detection
โ€ข Region Exiting Detection
โ€ข Object Abandoned Detection
โ€ข Object Removal Detection
โ€ข Loitering Detection
โ€ข People Detection
โ€ข Vehicle Detection
โ€ข Abnormal Sound Detection
โ€ข Scene Change Detection
Basic Event โ€ข Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)
โ€ข Video Tampering Detection
โ€ข Exception ( Illegal Login)
Alarm Linkage โ€ข Memory Card Video Recording
โ€ข Message Push
โ€ข Audible Warning
โ€ข White Light Flashing
Linkage Method N/A
Output Notification Message Push
Deep Learning Function
People & Vehicle Analytics Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.ยง
INTERFACES
Network Interface 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm N/A
Reset Button Yes
Power DC Power Port
On-board Storage Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB**
Built-in Microphone Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera
Built-in Speaker Yes
Audio N/A
GENERAL
Operating Temperature -30โ€“60 ยฐC
Storage Temperature -40โ€“60 ยฐC
Operating Humidity 95% or Less (Non-Condensing)
Storage Humidity 95% or Less (Non-Condensing)
Package Content โ€ข VIGI Network Camera
โ€ข Quick Start Guide
โ€ข Waterproof Cable Attachments
โ€ข Mounting Accessories
Material Metal
Net Weight 0.525 Kg
Power Supply โ€ข 12V DC ยฑ 5%, Max. 10.5 W, 5.5 mm Coaxial Power Plug
โ€ข PoE: 802.3af/at, class 0, Max. 11.5 W
Protection IP67
Product Dimensions (L x W x H) 7.2 ร— 2.9 ร— 2.9 in (184 ร— 74 ร— 74 mm)
Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC
